Step 1: Surface Preparation

Proper preparation is the most important step in achieving a flawless finish.



✅ Clean and Dry the Surface Thoroughly

Start by sweeping and vacuuming the entire surface to remove loose dust and debris. Use a degreaser or detergent if there are oil stains or any form of contamination. It’s essential that the surface is:



 Free from oil, grease, dust, and loose particles

 Completely dry before application

✅ Repair Any Cracks or Holes

For the best finish, patch up holes or cracks using a concrete repair mortar or filler. The final appearance of the floor will reflect the quality of your preparation—so take the time to ensure the surface is smooth and solid.



✅ Etch, Grind, or Scarify for Adhesion

For best results, especially on power-floated or sealed concrete, mechanically prepare the surface using a floor grinder or scarifier. This helps the epoxy coating bond effectively and reduces the risk of delamination. Floor grinders are widely available for hire at most tool rental stores.



Recommended Surface Temperature:

Between 5°C and 25°C.

Too cold and the epoxy may not cure properly. Too warm and it could cure too quickly to work with.



⚙️ Step 2: Product Preparation

Everest Trade HB Epoxy floor paint is a two-part system, consisting of a resin base (Part A) and an activator (Part B). Once mixed, you’ll have a pot life of roughly 30 minutes, so only mix what you can apply in that window.



✅ Get Your Mixing Station Ready

Prepare a clean, disposable area with plastic sheeting or cardboard to catch any spills.



✅ Tools You’ll Need:

 Electric drill with paddle mixer

 ProDec 24" Drill Fit Stirrer (specially designed for epoxy mixing)

 Paint scuttle or tray

 Heavy-duty roller application kit

 Paintbrushes for edging

 Masking tape (optional)

✅ Mixing Instructions:

Stir Part A (resin) on its own for 1–2 minutes.

Add Part B (activator) and continue mixing thoroughly for another 1–2 minutes.

Ensure there are no streaks or unmixed material—consistency is key.

⚠️ Don’t delay—once mixed, you have 30 minutes before the product begins to cure.



�� Step 3: Applying the Epoxy Floor Paint

With your surface prepared and your first unit mixed, it’s time to get painting.



✅ Cut In Around Edges First

Use a brush to paint along the edges, corners, and hard-to-reach areas first. This allows you to roll freely without needing to pause later for detailing.



✅ Work in Measured Sections

Mark out your floor in sections based on your coverage rate. A 5kg unit will cover approximately 17–20m² depending on surface porosity. This helps ensure even thickness and prevents running out mid-way.



✅ Begin Rolling

Pour the mixed epoxy into a scuttle or tray and apply with a heavy-duty roller. Roll in thin, even layers using an M or W motion, ensuring no puddling.



⚠️ Expect the First Coat to Look Patchy

This is completely normal on bare concrete or porous floors. The second coat will even everything out and provide the full gloss finish.



✅ Remove Masking Tape

If using masking tape, remove it carefully before the paint begins to cure to avoid tearing or pulling at the surface.



⏱️ Step 4: Curing and Second Coat

✅ Allow the First Coat to Cure

At 20°C, allow the paint to cure for at least 12 hours. The surface should be touch dry before proceeding.



✅ Apply the Second Coat

Mix a new batch using the same method and apply the second coat within 24 hours of the first. This coat will provide:



 Full colour depth

 High-gloss finish

 Enhanced chemical and abrasion resistance

Let the second coat cure for 12–16 hours before walking on the surface. For vehicle traffic, wait 48 hours. Avoid cleaning or exposing the floor to water for 7 days, after which full chemical resistance will be achieved.



�� Step 5: Aftercare and Maintenance

Now that your floor is finished, maintenance is simple:






 Clean with mild detergents (no acidic or alkaline cleaners)

 Avoid dragging sharp objects across the surface

 Recoat only when surface dulls or wears—typically every 3–5 years

1. What is Oil-based Epoxy Topcoat?

An oil-based epoxy topcoat is a high-performance coating composed of epoxy resins mixed with oil-based solvents. This type of paint is commonly used to provide protective and decorative finishes for various surfaces in industrial, commercial, and residential environments. It combines the robust durability of epoxy with the flexibility of oil-based paints, making it ideal for use on concrete floors, metal surfaces, equipment, machinery, and structures exposed to harsh conditions.

The unique formulation of oil-based epoxy topcoats offers superior resistance to chemicals, corrosion, abrasion, and weathering. These coatings are highly valued for their durability and versatility, making them a preferred choice in industries such as manufacturing, automotive, construction, and marine applications.

2. Key Features of Oil-based Epoxy Topcoat

Oil-based epoxy topcoats are well-known for their range of benefits, which make them suitable for a variety of applications. Some of the key features include:

2.1 Exceptional Durability

Oil-based epoxy topcoats are renowned for their excellent durability. They form a strong, hard-wearing surface that resists abrasion and impact, making them ideal for high-traffic areas like factory floors, warehouses, and garages. Their ability to withstand heavy use and physical stress ensures long-lasting protection for surfaces.

2.2 Superior Corrosion Resistance

One of the primary advantages of an oil-based epoxy topcoat is its remarkable corrosion resistance. These coatings protect metal surfaces from rust and deterioration caused by exposure to water, chemicals, and environmental elements. Whether used in coastal environments, industrial factories, or outdoor structures, oil-based epoxy coatings prevent the damaging effects of rust and corrosion.

2.3 Strong Adhesion

Oil-based epoxy coatings are known for their strong adhesion properties. They bond effectively to a wide range of substrates, including concrete, steel, aluminum, wood, and more. This ensures that the coating stays intact and provides long-term protection, even in demanding environments.

2.4 Aesthetic Enhancement

In addition to offering practical protection, oil-based epoxy topcoats also enhance the appearance of surfaces. These coatings can provide a smooth, glossy finish that enhances the visual appeal of floors and equipment. Available in a variety of colors and finishes (including high gloss, semi-gloss, and matte), epoxy topcoats offer flexibility in design and customization.

2.5 Chemical Resistance

Oil-based epoxy topcoats offer excellent chemical resistance, making them suitable for areas that are exposed to harsh chemicals, oils, solvents, and acids. This characteristic makes them particularly useful in industrial and manufacturing environments, where exposure to chemicals is common.

3. Applications of Oil-based Epoxy Topcoat

Oil-based epoxy topcoats are used in a wide range of applications across various industries. Their unique blend of durability, corrosion resistance, and aesthetic quality makes them suitable for:

3.1 Industrial Facilities

Oil-based epoxy coatings are extensively used in industrial settings, such as chemical plants, power stations, and manufacturing facilities. These environments require coatings that can withstand heavy machinery, high temperatures, and exposure to corrosive materials. Oil-based epoxy topcoats provide a robust solution to protect surfaces from wear and chemical degradation.

3.2 Floor Coatings

Oil-based epoxy is a popular choice for flooring in warehouses, garages, factories, and high-traffic commercial spaces. Its superior abrasion resistance and chemical resistance make it ideal for protecting floors from stains, oil spills, and daily wear. The smooth, glossy finish also makes the surface easy to clean, contributing to a safer and more hygienic environment.

3.3 Concrete and Cement Surfaces

Oil-based epoxy coatings are highly effective on concrete and cement surfaces, providing a protective layer that guards against moisture, stains, and chemical damage. Whether applied to floors, walls, or countertops, oil-based epoxy creates a durable and seamless surface that prevents degradation of concrete structures.

3.4 Metal Equipment and Machinery

Oil-based epoxy topcoats are often used to protect metal equipment, tools, and machinery. These coatings prevent rust and corrosion, extending the lifespan of metal surfaces that are exposed to water, chemicals, or harsh environmental conditions. Common applications include the coating of steel beams, bridges, pipelines, and marine vessels.

3.5 Marine and Outdoor Structures

Oil-based epoxy topcoats are particularly effective in outdoor and marine environments, where exposure to saltwater, UV rays, and harsh weather conditions is common. These coatings provide excellent protection against corrosion and degradation, ensuring that structures such as ships, offshore platforms, and outdoor equipment remain durable and functional for longer periods.

4. Application Process of Oil-based Epoxy Topcoat

Applying oil-based epoxy topcoat requires careful surface preparation and attention to detail to ensure the best results. Below are the general steps involved in the application process:

4.1 Surface Preparation

Proper surface preparation is essential for achieving a high-quality finish. Surfaces should be clean, dry, and free from contaminants such as dust, dirt, grease, or rust. For metal surfaces, it is often necessary to remove any existing rust or oxidation using sandpaper or a wire brush. Concrete surfaces may need to be cleaned and ground to ensure proper adhesion.

4.2 Mixing the Coating

Before applying the epoxy topcoat, it is essential to mix the base resin with the curing agent (hardener) in the correct proportions. Follow the manufacturer's guidelines for mixing to ensure that the epoxy cures properly. Thorough mixing ensures that the hardener is evenly distributed throughout the resin, resulting in a smooth and consistent coating.

4.3 Applying the Coating

Once the epoxy is properly mixed, it can be applied to the prepared surface. Depending on the application area, oil-based epoxy can be applied using brushes, rollers, or spray equipment. Ensure an even application and avoid applying the coating too thickly, as this can lead to drips or an uneven finish.

4.4 Drying and Curing

After the epoxy topcoat is applied, it needs time to dry and cure. Drying times can vary depending on environmental conditions, such as temperature and humidity. Typically, oil-based epoxy coatings require 24 to 48 hours to fully cure, but it is important to allow the coating to cure for the recommended time before subjecting the surface to any stress or traffic.

4.5 Maintenance and Inspection

Once the coating has cured, it is essential to perform regular inspections to ensure that it remains intact. Periodic maintenance may be required to touch up any areas of wear or damage. If cracks or chips occur, it is important to address these promptly to maintain the integrity of the coating.

5. Advantages and Disadvantages of Oil-based Epoxy Topcoat

5.1 Advantages

  • Exceptional Durability: Oil-based epoxy topcoats offer unmatched durability, making them ideal for high-traffic and industrial environments where durability is paramount.

  • Chemical and Abrasion Resistance: These coatings provide excellent resistance to chemicals, solvents, oils, and abrasion, making them suitable for demanding applications.

  • Versatile Applications: They can be used on a wide variety of surfaces, including concrete, metal, and wood, providing protection across different industries.

  • Aesthetic Appeal: Available in a range of finishes and colors, oil-based epoxy topcoats enhance the appearance of surfaces while providing long-lasting protection.

5.2 Disadvantages

  • Longer Drying Times: Compared to water-based coatings, oil-based epoxy topcoats generally take longer to dry and cure. This can lead to longer downtime during application.

  • Strong Odor: Oil-based coatings tend to emit strong odors due to the solvents used in the formulation. Proper ventilation is necessary during application to minimize exposure to fumes.

  • Environmental Impact: The solvents in oil-based coatings can have a higher environmental impact than water-based alternatives, making them less desirable in environmentally-conscious applications.

  • Surface Sensitivity: While epoxy coatings are durable, they can be susceptible to UV degradation if not properly protected from direct sunlight, leading to yellowing or chalking over time.

6. Conclusion

Oil-based epoxy topcoats are an excellent choice for a variety of industrial, commercial, and residential applications. Their combination of durability, corrosion resistance, and aesthetic appeal makes them an ideal solution for protecting floors, metal surfaces, machinery, and more. While they require proper surface preparation and application techniques, the benefits of using oil-based epoxy coatings far outweigh the potential challenges, offering long-lasting protection and enhancing the performance and appearance of surfaces.
